PLAN SUMMARY
-
Stories
2
-
Bedrooms
6
-
Bathrooms
4
-
Garage
3 car
-
Width x Length:
54' 9" x 82' 2"
-
First Floor Sq Ft
2,327 Sq. Ft.
-
Second Floor Sq Ft
2,554 Sq. Ft.
-
Total AC Sq Ft
4,881 Sq. Ft.
-
Total Under Roof Sq Ft
6,170 Sq. Ft.
$0.00
Plan Description
This luxurious, Mediterranean-style, two-story home features six bedrooms, three and one-half bathrooms, a cabana bathroom and three-car garage. Columns and arches provide strong curb appeal. The huge island kitchen with an eating bar and pantry opens to the family room. A spectacular living room shows off the raised ceilings. The den offers a private area for entertaining or simple solitude. You’ll love this design if you seek a home that is spacious and also provides private places to escape and relax! The family room opens to a covered patio with a summer kitchen. The master suite is truly luxurious with the large walk-in closets and a luxurious master bath.
Dimensions
-
Width x Length
54' 9" x 82' 2"
-
Height
31'-5
-
Stories
2/
Garage
-
Number of Cars
3
-
Attached
Yes
-
Location
Left
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
6
-
Possible
0
-
Total
6
Bathrooms
-
Full
4
-
Half
1
-
Total
4
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
2
Features
-
Fireplace
No
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1600
CAD Disk Price: $2400
Reverse PDF Price: $1850
Reverse CAD Price: $2650
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $1100
3 Sets Price: $1200
5 Sets Price: $1300
8 Sets Price: $1450
Reproducible Vellum Price: $1600
Base – Not for Construction Price: $1100
3 Sets (Reverse) Price: $1450
5 Sets (Reverse) Price: $1550
8 Sets (Reverse) Price: $1700
Reproducible Vellum (Reverse) Price: $1850
Foundation Type
-
Type
Wood Truss
-
Option
0
Floor System
-
Type
gypcrete
-
Spacing
-
Subfloor
wood
-
Thickness
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
s. tile
-
Wind Speed
140
First Floor
-
Primary Living
22' to 20'-8
-
Secondary Living
10'-6
-
Primary Bedrooms
-
Secondary Bedrooms
10'-6
-
Bathrooms
9'
-
Common Areas
10'-6
Second Floor
-
Primary Bedrooms
9'-4
-
Secondary Bedrooms
9'-4
-
Bathrooms
9'-4
-
Common Areas
9'-4
Exterior
-
Garage
10'-8
-
Covered Entry
10'-8
-
Covered Patio
10'-8
-
Covered Balcony
9'-4
Total AC Sq Ft
-
First Floor AC
2327
-
Second Floor AC
2554
-
Total AC
4881
Total Under Roof Sq Ft
-
Garage
611
-
Covered Entry
168
-
Covered Patio
408
-
Covered Balconies
102
-
Total Under Roof
6170
