PLAN SUMMARY
-
Stories
1
-
Bedrooms
5
-
Bathrooms
3.5
-
Garage
3 car
-
Width x Length:
76' 9" x 113' 8"
-
First Floor Sq Ft
3,840 Sq. Ft.
-
Total AC Sq Ft
3,840 Sq. Ft.
-
Total Under Roof Sq Ft
5,598 Sq. Ft.
-
$0.00
Plan Description
One Story
Five Bedrooms
Three Car Garage
Three and a Half Bathrooms
Modern style
This five bedroom home is full of amenities
Spacious Living and Dining areas
Large Master Suite has dual walk-in-closet and a grand
Master Bath
Open concept layout
Large covered patio
Dimensions
-
Width x Length
76' 9" x 113' 8"
-
Height
25'
-
Stories
1/
Garage
-
Number of Cars
3
-
Attached
No
-
Location
Left
Wall Construction
-
Interior
Metal Stud
-
Exterior
CMU Block
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
5
-
Possible
-
Total
5
Bathrooms
-
Full
3
-
Half
1
-
Total
3.5
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
-
Utility Location
Features
-
Fireplace
No
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1400
CAD Disk Price: $2100
Reverse PDF Price: $1650
Reverse CAD Price: $2350
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $900
3 Sets Price: $1000
5 Sets Price: $1100
8 Sets Price: $1250
Reproducible Vellum Price: $1400
Base – Not for Construction Price: $900
3 Sets (Reverse) Price: $1250
5 Sets (Reverse) Price: $1350
8 Sets (Reverse) Price: $1500
Reproducible Vellum (Reverse) Price: $1650
Foundation Type
-
Type
Mono
-
Option
Floor System
-
Type
Concrete
-
Spacing
-
Subfloor
-
Thickness
Roof System
-
Type
Wood Trusses
-
Options
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
-
Roof: Dead Load
-
Floor: Live Load
-
Floor: Dead Load
-
Roof Material
Cement Tiles
-
Wind Speed
170
First Floor
-
Primary Living
12' to 13' 4
-
Secondary Living
-
Primary Bedrooms
12' to 13' 4
-
Secondary Bedrooms
10'
-
Bathrooms
10'
-
Common Areas
Exterior
-
Garage
-
Covered Entry
14'
-
Covered Patio
12'
-
Covered Balcony
Total AC Sq Ft
-
First Floor AC
3840
-
Total AC
3840
Total Under Roof Sq Ft
-
Garage
823
-
Covered Entry
170
-
Covered Patio
765
-
Covered Balconies
-
Total Under Roof
5598
